Trim Tabs
Super Trim Control
Higher Speed
Lower Fuel Consumption
Stainless Steel
IsoTech ehf. have manufactured Actuators for Trim Tabs since 1997. They are made of high quality AISI 316 grade stainless steel and fullfills the IP68 Standard for dust and watertightness. The Actuators have been proven to be reliable and durable in North Atlantic sea waters.
For small to large vessel and racing application
| Size Chart | |||||
| Trim Tabs | |||||
| Thickness | 2,5mm | 3mm | |||
| Standard | Heavy Duty | ||||
| Boat Length | Boat Length | Tab size mm | Actuators | Tab size mm | Actuators |
| Meters | Foot | Length width | Qty. | Length width | Qty. |
| 5-6 m | 15-18´ | 250 x 250 | 1 pc | 250 x 350 | 1 pc |
| 6-8 m | 18-24´ | 250 x 450 | 1 pc | 3000 x 500 | 1 pc |
| 8-10 m | 24-30´ | 300 x 600 | 1 pc | 400 x 620 | 1 pc |
| 10-12 m | 30-36´ | 300 x 700 | 1 pc | 450 x 700 | 1 pc |
| 12-14 m | 36-42´ | 400 x 800 | 1 pc | 500 x 800 | 1 pc |
| 14-16 m | 42-48´ | 400 x 900 | 2 pcs | 500 x 900 | 2 pcs |
| 16-18 m | 48-54´ | 500 x 900 | 2 pcs | 500 x 1000 | 2 pcs |
| 18-20 m | 48-52´ | 500 x 1000 | 2 pcs | 500 x 1100 | 2 pcs |
| 20-22 m | 60-66´ | 600 x 1000 | 2 pcs | 600 x 1200 | 3 pcs |
